Interesting Facts

In 2008 the EPA took the lead and nickel out of the hot dipped galvanize. I bought all the hot dipped galvanized frames i could,built before 2009 at scrap prices,so the trailer manufacturers could buy the aluminum to get a head start in the aluminum trailer business. Some of the trailer builders that did not get in the race,went under.Sportsman trailers in Texas was one of them. I bought about 200 of there frames. These frames were all built for mono hulls.I build my sail boat trailers with these frames. I go up with a 2" galvanized pipe,then weld two 3/4" nuts near the top.I brace the risers with two are three 1 1/2"x1/4" angle iron braces with a 1 1/2" pipe telescoping up and down with a swivel pad or runners.

Trailers

J 22 and J 24 trailer fits most any boat with a deep draft.The axles are on slides U-bolted to frame

J 22 and J 24 trailer fits most any boat with a deep draft.The axles are on slides U-bolted to frame so you can add another axle.

This trailer is 30 ft . It will adjust to any sail boat are mono hull boat. It is galvanized It is 42 years old. I has the good galvanize.and great American steel.

Galvanized with three 5200 lb axle, 10 risers, adjustable to fit deep drafts

25 to 28 ft shallow draft or swing keel

Painted trailer with 10 risers, 37ft long, with three 5200 lb axles,surge brake on two axles. It is ready to go. Call it will sell fast.

This trailer carried the boat 10,000 mi. It is for sale for $2,500.I will add a bow stop

Yard trailer that can be converted later for road trailer we can add one more 4500 lb axle and adjust the bow stop. The bow stop is U-bolted to the tongue. When you have completed the work and ready for the road. We can assist you in completing the trailer.

Rubber bushing under keel board to take the shock off the keel.

Painted trailer for Catalina 25

J24
Hunter 26
Oday24
$2300

24 ft frame for 30 ft boat for three axles

This trailer was made for a 5500 lb boat. We are able to add another slide with axles, brake, and fenders to accommodate an 8000 lb boat. Also the two axles were on slides U-bolted to frame.

J27 1985 had to add another axle. It had 700 lbs of water absorbed in hull. By having axles on slides, we saved him about $2200.One happy camper.

more trailers

Trailer on right, before uprights we go up with 2" galvanize pipe with 1 1/2" to telescope up and down with swivel pad on top.On top of 2" we weld two 3/4" nuts to hold the 1 1/2" That is a big bolt.

Trailer frame before up rights installed

This picture is to show you the extensions with tires we build.We can build any length. We also build extensions for the tongue.These are built with 3x3 tubing,no wheels. if they are under 8 ft we can ship for under $50.
